Assignment of Functions to User Buttons

You can assign functions to the following buttons and use them as user buttons.

By assigning functions to the buttons, the usability of the camera recorder can be enhanced.

Perform settings in the menu items corresponding to each button.

Button

Menu Item

[USER0] Switch

[USER0]

[USER1] Button

[USER1]

[USER2] Switch

[USER2]

[USER3] Button

[USER3]

[USER4] Button

[USER4]

[ONLINE/5] Button

[USER5]

[USER6] Button

[USER6]

[USER7] Button

[USER7]

[AWB/USER8] Switch

[USER8]

[ U_botton ] Button

[USER9 ▲]

[ D_botton ] Button

[USER10 ▼]

[ L_botton ] Button

[USER11 ◀]

[ R_botton ] Button

[USER12 ▶]

[SET/USER13] Button

[USER13 ●(Front)]

[USER1] Button (VF)

[USER1 (VF)]

[USER2] Button (VF)

[USER2 (VF)]

[RET] Button on the Lens

[LENS RET]
HC900 USER_ButtonST
Assign functions to the buttons from the menu.

Configure each item to the user buttons in [Camera Function] arrowR [User Switch Set].

User Switch Set Item
Memo

Operations of the user buttons are interlocked with the menu settings.

When the menu screen is displayed, these buttons function as the menu operation buttons.

Basic Operations in Menu Screen
