The power status is displayed on the display and menu screens.
Power Status Display
Viewfinder Screen and LCD Monitor
|
Display |
Description |
|---|---|
|
|
Currently powered by a battery. Memo
You can set the display using [LCD/VF] |
|
|
Currently powered by DC power. |
|
|
A warning display when the supply voltage of the DC power is low. |
14.4V
30%
RES
[Display Type]
Memo
The battery mark that indicates the battery level may not appear depending on the battery in use.
When the battery that is connected does not support communication, the voltage is displayed regardless of the setting.
Display Screen
Menu Screen
Warnings by Lamp and Warning Tone
Warning status is indicated by tally lamp and warning tone.
The front and back tally lamps of the camera recorder appear blinking.
The warning tone is output from the speaker or [PHONE] terminal.
Adjust the volume level using the [ALARM] volume adjustment knob.
Memo
If you continue to use the camera recorder while the power warning is displayed, the camera recorder will stop automatically when the battery or supplied voltage from the DC power becomes lower.
Caution
The remaining battery power and time are displayed as they are from the battery information. Accurate data may not be displayed depending on the battery condition. Replace the battery as soon as possible when the remaining battery power and time are low.
